This is a 2½ DMA SERIES PASSIVE RADIATOR of brand Dayton Audio.

SALIN is a leading Australian appliance spare parts distributer . We take pride in our ability to bring hard to find appliance spare parts into the Australian market. We are proudly Australian owned and operated. Our warehouse and sales office is conveniently located in Auburn, NSW. Our range of spare parts are manufactured with premium components and quality material. Most of our range is directly sourced from manufacturers and geniune.

TECHNICAL SHEET
Title 2½ DMA SERIES PASSIVE RADIATOR
Notes DAYTON AUDIO Dayton Audios DMA70-PR 2-1/2 aluminium cone passive radiator allows you to tune small enclosures lower than possible using conventional ports. Matching the DMA series of drivers drivers perfectly, this passive radiator is perfect for use in ultra-small designs like smart speakers, sound bars, and portable Bluetooth speakers. - Perfect match for the Dayton Audio DMA series drivers Allows tuning small enclosures lower than possible using conventional ports Rear mounted threaded post allows easy mass adjustment for custom tuning DIY friendly, oversized mounting flange makes installation simple - The DMA70-PR 2-1/2 passive radiator from Dayton Audio is the perfect option for achieving low tuning frequencies from the smallest enclosure designs. This incredibly small passive radiator has all the features you would expect lager units including adjustable mass, aluminium cone, and rubber surround. Visually identical to Dayton Audios full-range DMA series drivers, the DMA70-PR can also be used with any small driver that requires a low tuning frequency. The threaded rod and included wing nut on the back of the cone makes it easy to add mass to tune the radiator as needed for your projects. Whether you are building a smart speaker, sound bar, or portable Bluetooth speaker, the Dayton Audio DMA70-PR introduces a new range of possibilities. Specifications: • Fs: 34.5 Hz • Vas: 0.046 ft³ (1.32 liters) • Qms: 3.86 • Cms: 1.77 mm/N • Mms: 12.0 g • Rms: 1.49 kg/s • Sd: 22.9 cm² • Xmech: 7 mm • Dimensions: Overall diameter: 2.75 x 2.75, Cutout diameter: 2.52, Depth: 1.73. Tip: As a general rule, the passive radiator(s) should have at least double the displacement of air (Vd) as the active woofer(s)/subwoofer(s) in the system. To calculate Vd: Sd x Xmax = VdThe DMA70-PR 2-1/2 passive radiator from Dayton Audio is the perfect option for achieving low tuning frequencies from the smallest enclosure designs. This incredibly small passive radiator has all the features you would expect lager units including adjustable mass, aluminum cone, and rubber surround. Visually identical to Dayton Audios full-range DMA series drivers, the DMA70-PR can also be used with any small driver that requires a low tuning frequency. The threaded rod and included wing nut on the back of the cone makes it easy to add mass to tune the radiator as needed for your projects. Whether you are building a smart speaker, sound bar, or portable Bluetooth speaker, the Dayton Audio DMA70-PR introduces a new range of possibilities. Specifications: • Fs: 34.5 Hz • Vas: 0.046 ft³ (1.32 liters) • Qms: 3.86 • Cms: 1.77 mm/N • Mms: 12.0 g • Rms: 1.49 kg/s • Sd: 22.9 cm² • Xmech: 7 mm • Dimensions: Overall diameter: 2.75 x 2.75, Cutout diameter: 2.52, Depth: 1.73. Tip: As a general rule, the passive radiator(s) should have at least double the displacement of air (Vd) as the active woofer(s)/subwoofer(s) in the system. To calculate Vd: Sd x Xmax = VdPerfect match for the Dayton Audio DMA series driversAllows tuning small enclosures lower than possible using conventional portsRear mounted threaded post allows easy mass adjustment for custom tuningDIY friendly, oversized mounting flange makes installation simple
DescriptionDMA70-PR 2-1/2' DMA Series Passive Radiator
ManufacturerDayton Audio
TypePassive Radiator
ColourBlack
Hole63.8mmØ
QTY1
ImpedancePassive
Depth44mm
Qms3.86
Vas1.32L
Sd22.9 cm²
Cms1.77 mm/N
Fs34.5 Hz
Mms12.0 g
Rms0.67 kg/s
Xmax7 mm
Diam.70x70mm
Vd16.0 cm³
SeriesFull-Range
Inch2.5
Size2.5'
UPC848791005626
Brand.Dayton Audio
Price Typeeach
SKU NoWES_DMA70-PR_1



SALIN is not responsible for any possible damage caused by misselection and incorrect installation of the spare parts.

All electrical items must be fitted by a qualified electrician.

Errors and Omissions Excepted:

All information contained herein this website is assumed to be accurate, however, no responsibility is assumed by SALIN  for its use, nor for any infringements of patents or other rights of third parties which may result from its use.

Legal Disclaimer:

All trademarks, logos and principal representations remain the property of their respective owners. The use of brands, brand names and trademarks doesn't imply SALIN is representing those brands, companies, trademarks or names. SALIN holds no rights to products and/or services available or provided by the said companies, brands, brand names and trademarks.

MPN DMA70-PR
SKU WES_DMA70-PR_1
Brand Dayton Audio
