This is a 3 DMA SERIES PASSIVE RADIATOR - DAYTON AUDIO of brand Dayton Audio.

SALIN is a leading Australian appliance spare parts distributer . We take pride in our ability to bring hard to find appliance spare parts into the Australian market. We are proudly Australian owned and operated. Our warehouse and sales office is conveniently located in Auburn, NSW. Our range of spare parts are manufactured with premium components and quality material. Most of our range is directly sourced from manufacturers and geniune.

TECHNICAL SHEET
Title 3 DMA SERIES PASSIVE RADIATOR - DAYTON AUDIO
Notes Dayton Audios DMA80-PR 3 aluminum cone passive radiator allows you to tune small enclosures lower than possible using conventional ports. Matching the DMA series of drivers drivers perfectly, this passive radiator is perfect for use in ultra-small designs like smart speakers, sound bars, and portable Bluetooth speakers. - Perfect match for the Dayton Audio DMA series drivers Allows tuning small enclosures lower than possible using conventional ports Rear mounted threaded post allows easy mass adjustment for custom tuning DIY friendly, oversized mounting flange makes installation simple - The DMA80-PR 3 passive radiator from Dayton Audio is the perfect option for achieving low tuning frequencies from the smallest enclosure designs. This incredibly small passive radiator has all the features you would expect lager units including adjustable mass, aluminum cone, and rubber surround. Visually identical to Dayton Audios full-range DMA series drivers, the DMA80-PR can also be used with any small driver that requires a low tuning frequency. The threaded rod and included wing nut on the back of the cone makes it easy to add mass to tune the radiator as needed for your projects. Whether you are building a smart speaker, sound bar, or portable Bluetooth speaker, the Dayton Audio DMA80-PR introduces a new range of possibilities. Specifications: • Fs: 34.6 Hz • Vas: 0.071 ft³ (1.9 liters) • Qms: 8.91 • Cms: 1.41 mm/N • Mms: 13.7 g • Rms: 0.35 kg/s • Sd: 31.2 cm² • Xmech: 7 mm • Dimensions: Overall diameter: 3.17 x 3.17, Cutout diameter: 2.93, Depth: 1.76.The DMA80-PR 3 passive radiator from Dayton Audio is the perfect option for achieving low tuning frequencies from the smallest enclosure designs. This incredibly small passive radiator has all the features you would expect lager units including adjustable mass, aluminum cone, and rubber surround. Visually identical to Dayton Audios full-range DMA series drivers, the DMA80-PR can also be used with any small driver that requires a low tuning frequency. The threaded rod and included wing nut on the back of the cone makes it easy to add mass to tune the radiator as needed for your projects. Whether you are building a smart speaker, sound bar, or portable Bluetooth speaker, the Dayton Audio DMA80-PR introduces a new range of possibilities. Specifications: • Fs: 34.6 Hz • Vas: 0.071 ft³ (1.9 liters) • Qms: 8.91 • Cms: 1.41 mm/N • Mms: 13.7 g • Rms: 0.35 kg/s • Sd: 31.2 cm² • Xmech: 7 mm • Dimensions: Overall diameter: 3.17 x 3.17, Cutout diameter: 2.93, Depth: 1.76.Perfect match for the Dayton Audio DMA series driversAllows tuning small enclosures lower than possible using conventional portsRear mounted threaded post allows easy mass adjustment for custom tuningDIY friendly, oversized mounting flange makes installation simple
DescriptionDMA80-PR 3' DMA Series Passive Radiator
ManufacturerDayton Audio
TypePassive Radiator
ColourBlack
Hole74mmØ
QTY1
ImpedancePassive
Depth45mm
Qms8.91
Vas2.14L
Sd31.2 cm²
Cms1.41 mm/N
Fs34.6 Hz
Mms13.7 g
Rms0.33 kg/s
Xmax7 mm
Diam.80x80mm
Vd21.8 cm³
SeriesFull-Range
Inch3
Size3'
UPC848791005633
Brand.Dayton Audio
Price Typeeach
SKU NoWES_DMA80-PR_1
