This is a 3¼ HORN BULLET of brand Daichi.

SALIN is a leading Australian appliance spare parts distributer . We take pride in our ability to bring hard to find appliance spare parts into the Australian market. We are proudly Australian owned and operated. Our warehouse and sales office is conveniently located in Auburn, NSW. Our range of spare parts are manufactured with premium components and quality material. Most of our range is directly sourced from manufacturers and geniune.

TECHNICAL SHEET
Title 3¼ HORN BULLET
Notes 22mmØ PIEZO 50Wrms KSN1005A REPLACEMENT Piezo horn loaded tweeter. Replacement for KSN1005A 22mm Ceramic Piezo 50Wrms 60mm deep Exponential horn.
Description3¼' HOR BULLET
Size3.5'
Price Typeeach
Power75Wmax
Freq.4KHz - 27KHz
QTY1
Sens.94dB
ManufacturerDaichi
Dimensions80x80mm
Impedance (Ohm)Piezo
Power (RMS)0-50 Watt
Inch3.5
Hole-
Mount-
Fo-
Fs-
Re0.3uF
Coil22mm
Prms50W
Depth65mm
Diam.80x80mm
SPL94dB
Brand.Daichi
OEMKSN1005
ImpedancePiezo
ZnPiezo
SeriesPiezo
MaterialsPiezo
Mag.Piezo 22mm
TypeTweeter Horn
SKU NoWES_PZ1005_1
