4x4 COMPONENT MATRIX SWITCH + DIGITAL AUDIO
RGB/YUV + L/R PLUS DIGITAL AUDIO
SKU code: WES_CCMX-44DA_3
This is a 4x4 COMPONENT MATRIX SWITCH + DIGITAL AUDIO of brand Cypress.
SALIN is a leading Australian appliance spare parts distributer . We take pride in our ability to bring hard to find appliance spare parts into the Australian market. We are proudly Australian owned and operated. Our warehouse and sales office is conveniently located in Auburn, NSW. Our range of spare parts are manufactured with premium components and quality material. Most of our range is directly sourced from manufacturers and geniune.
| TECHNICAL SHEET | |
|---|---|
| Title | 4x4 COMPONENT MATRIX SWITCH + DIGITAL AUDIO |
| Notes | RGB/YUV + L/R PLUS DIGITAL AUDIO High performance Component of Digital/Analog Audio with Video Matrix. It offers you maximum convenience in HDTV audio/video signal distribution when you have multiple sources to display. Each of the four HDTV audio/video sources can be directed to any one of the four outputs and or all four displays can show one identical output sources at the same time. It provides a variety of choices on where to play your image with remote controller. Each input can be direct to any/all output. Audio format of Digital or Analog both acceptable.Provides 4 by 4 matrix input/output of Component (YPbPr/YCbCr) video and L/R & Coaxial digital audio signal. Buffered video and audio output. Input source LED indicators on each output select. Ideal for home theatre integration, conference room and retail stores. Supports high resolution input/output.HDTV: 480i, 576i, 480p, 576p, 1080i, and 1080p. Supports analog stereo L/R audio input and output. Support Coaxial audio input and output. IR remote control. RS-232 control. |
| Description | Matrix 4x4 Digital Audio |
| Input | 4× Component Video |
| Output | 4× Component Video |
| Interface | Component |
| Compliance | - |
| 3D | - |
| CEC | - |
| EDID | - |
| Cascade | - |
| Max Res. | UXGA/1080p |
| Chassis. | Metal |
| HDCP | - |
| Page | 18 |
| YUV Input | 4 |
| YUV Output | 4 |
| Manufacturer | Cypress |
| SKU No | WES_CCMX-44DA_3 |
SALIN is not responsible for any possible damage caused by misselection and incorrect installation of the spare parts.
All electrical items must be fitted by a qualified electrician.
Errors and Omissions Excepted:
All information contained herein this website is assumed to be accurate, however, no responsibility is assumed by SALIN for its use, nor for any infringements of patents or other rights of third parties which may result from its use.
Legal Disclaimer:
All trademarks, logos and principal representations remain the property of their respective owners. The use of brands, brand names and trademarks doesn't imply SALIN is representing those brands, companies, trademarks or names. SALIN holds no rights to products and/or services available or provided by the said companies, brands, brand names and trademarks.
| MPN | CCMX-44DA |
| SKU | WES_CCMX-44DA_3 |
| Brand | Cypress |
