Fujitsu Ducted Air Conditioner Indoor Unit Fan Motor

This is a replacement DC brushless indoor fan motor for Fujitsu slim duct ducted air conditioners. It drives the centrifugal fan inside the indoor unit that pulls return air through the filter and coil and pushes the conditioned air out into the duct run. The motor itself carries the designation MFG-09WVL. When it fails there is no airflow through the ducts, and because there is no air across the coil the system will either ice up in cooling or trip out on a protection fault.

Part Numbers

9603139018. Motor type MFG-09WVL. Not to be confused with 9603283018, which is the larger MFG-14WVAL motor used on the ARTG and ARXD 12 to 14 kW units.

OEM Genuine

This is an OEM genuine part. It is made by the original equipment manufacturer, the same company in the same factory that made the part fitted to your appliance when it was built, and it carries their part number. It is supplied to us without the appliance brand retail packaging, and that is the only reason it costs less than a boxed part bought from the brand. The part itself is the same part.

Suitable Brands

Fujitsu

Suitable Models

ARXK009GLEH, ARXK012GLEH, ARXK014GLEH, ARXD07LATH

When To Replace

Replace the motor when the indoor fan does not turn although the unit powers up, when there is no airflow at the outlets, when the fan runs at one speed only or will not change speed, when it is noisy, rattles or squeals, when the shaft is stiff or gritty to turn by hand with the power isolated, or when the unit reports an indoor fan motor fault. Check that the fan wheel is not jammed with dust and that the return air filter is not blocked before condemning the motor.

Fitting

This part must be fitted by a licensed refrigeration mechanic or a qualified electrician. Isolate the system at the circuit breaker before starting. Drop the access panel on the indoor unit, photograph the wiring and the position of the motor mounts, release the fan wheel from the shaft and withdraw the motor. Fit the new motor, refit the fan wheel square and free to turn, reconnect the wiring in the same order, then carry out insulation resistance and earth continuity tests and check airflow at every outlet before handing the system back.

Notes

Clean the fan wheel and the indoor coil while the unit is open, and fit a clean return air filter. A motor that has been fighting a dirty fan and a blocked coil has been running hot, and a new motor put back into the same conditions will not last.

TECHNICAL SHEET
Part No 9603139018
Product 9603139018 FUJITSU AIRCON INDOOR FAN MOTOR
Category Air Conditioning
Subcategory Air Conditioners
Class Air conditioners
Replacement Item Motor/Gearbox/Shaft
Suitable Brand Fujitsu
SKU Number SLN_0002519
