This is a replacement spare part. It is suitable for replacing UNIVERSAL Air Conditioners.

SALIN is a leading Australian appliance spare parts distributor for many types of applicances. We take pride in our ability to bring hard-to-find spare parts into the Australian market. We are proudly Australian-owned and operated. Our sales office is conveniently located in Sydney, NSW.

TECHNICAL SHEET
Title	AIR CONDITIONER REFRIGERANT RECOVERY UNIT VRR24M 1HP R410 R32 1234yf R134 R22
Brand	Universal
Suitable For	Air Conditioners
Model	VRR24M
MPN	VRR24M
Notes	DESCRIPTION RECOVERY UNIT VALUE VRR24M Economical recovery with 1 HP, oil-less compressor. Suitable for all commonly used refrigerants including R32 R410  1234yf ARI&CE certification approved. Oil separator.   Characteristic Value Refrigerants Category III: R12, R134a, R401C, R500, 1234yf. Category IV: R22, R401A, R401B, R402B, R407C, R407D, R408A, R409A, R411A, R411B, R412A, R502, R509. Category V: R402A, R404A, R407A, R407B, R410A, R507, R32. Power supply 220V/50Hz Motor DC 1 HP Motor speed 3000 rpm /50 Hz Maximal current draw 5A /230V compressor OIL-less, Air-cooled, piston style Automatic safety Shut-off 38.5 bar / 3850 kPa (558 psi) Recovery rate Category III   Category  IV  Category  V Vapor 0.40 kg/min. 0.50 kg/min. 0.52 kg/min. Liquid 3.30 kg/min. 3.85 kg/min. 3.85 kg/min. Push/pull 7.50 kg/min. 8.50 kg/min. 9.50 kg/min. Operating temperature 0°C - 40°C Dimensions 380x250x360 mm / 10,0 kg
SKU Number	EBY2_266274624974
