BOSCH PLENA ALL-IN-ONE MIXER AMPLIFIER 240W
6 INPUTS + BUILT-IN MEDIA PLAYER - 6 ZONE PAGING SYSTEM
SKU code: WES_PLN-6AIO240_1
This is a BOSCH PLENA ALL-IN-ONE MIXER AMPLIFIER 240W of brand Bosch.
SALIN is a leading Australian appliance spare parts distributer . We take pride in our ability to bring hard to find appliance spare parts into the Australian market. We are proudly Australian owned and operated. Our warehouse and sales office is conveniently located in Auburn, NSW. Our range of spare parts are manufactured with premium components and quality material. Most of our range is directly sourced from manufacturers and geniune.
| TECHNICAL SHEET | |
|---|---|
| Title | BOSCH PLENA ALL-IN-ONE MIXER AMPLIFIER 240W |
| Notes | 6 INPUTS + BUILT-IN MEDIA PLAYER - 6 ZONE PAGING SYSTEM Versatile all-in-one solution to cover all needs for background music (BGM), making announcements and paging people. The All‑in‑One Unit is a 3U high 19” wide rack‑mount unit. The unit is supplied with detachable rack‑mount brackets so that it can be used on a tabletop or installed in a rack. Inside the unit, the built‑in 240 Watt power amplifier of the All‑in‑One Unit makes this a complete single-channel audio system for music distribution and paging. The amplifier can accept up to six inputs that can be switched between microphone and line level sensitivity. The inputs are balanced or can be unbalanced. Phantom power can be switched to provide power to condenser microphones. The inputs can either be mixed or can be configured with different priority arrangements (serial/blocking/overriding), based on a signal detection at each input. The unit has six zone outputs for connection to different zones. The volume level of each zone can be attenuated separately.Apart from mic input, the unit has three music inputs and an internal music source. The internal music source plays MP3 files from an SD/MMC card or USB device with a capacity of up to 32 GB. The player will automatically search and play all playable MP3 files and has repeat and random play modes. If a microphone signal receives priority, the music is either muted or attenuated to an adjustable level (music ducking). The unit also has a built in AM/FM tuner with presets to tune in and store your favorite radio stations. An optional Wall Panel can be connected to the All‑in‑One Unit by use of a standard Cat‑5 cable and RJ45 connectors. The Wall Panel provides remote control of the system, as well as an input for a remote music player or microphone. The Enable button on the remote Wall Panel can be pressed to gain control over the music selection and master volume. This makes it the perfect accessory for a small system that requires operation from a second location with local audio inputs. This high performance yet affordable unit is very easy to install and operate. It is typically used in shops, supermarkets, restaurants, bars, schools, canteens, gyms, garages and other places where BGM creates the right atmosphere, and also amplified speech needs to be heard clearly. 133x430x365mmPowerful 240 W mono mixer amplifier with 6 zone output 8Ω/100V.All‑in‑One solution for background music and paging.Six‑zone paging system, so the output signal can be routed to 6 different zones with individual attenuation control.Media player that can play MP3 files from SD and USB devices.A built-in digital AM/FM-tuner with presetsSupports up to six microphones and three auxiliary source signals can be mixed, with priority or VOX switching. |
| Description | Plena 6AIO240 - 6 x main inputs (4 x mic, 2 x mic/line - XLR/TRS combo conn), 3 x music inputs (phono connectors), additional integrated FM tuner and USB input for MP3 audio file playback. 6 x zone outputs each with integrated output level control - 240W maximum output across 6 zones. 6 additional call stations - daisy chanined on CAT5 connection. |
| Mic. | 6 |
| Insert | Yes |
| Input | 6 |
| Output | 240Wrms |
| Manufacturer | Bosch |
| Zone | 6 |
| Audio Format | USB/SD/SDHD/MMC+ AM/FM |
| OEM | F.01U.275.392 |
| Details | USB/SD/SDHD/MMC+ AM/FM |
| SKU No | WES_PLN-6AIO240_1 |
SALIN is not responsible for any possible damage caused by misselection and incorrect installation of the spare parts.
All electrical items must be fitted by a qualified electrician.
Errors and Omissions Excepted:
All information contained herein this website is assumed to be accurate, however, no responsibility is assumed by SALIN for its use, nor for any infringements of patents or other rights of third parties which may result from its use.
Legal Disclaimer:
All trademarks, logos and principal representations remain the property of their respective owners. The use of brands, brand names and trademarks doesn't imply SALIN is representing those brands, companies, trademarks or names. SALIN holds no rights to products and/or services available or provided by the said companies, brands, brand names and trademarks.
| MPN | PLN-6AIO240 |
| SKU | WES_PLN-6AIO240_1 |
| Brand | Bosch |
