This is a EVAC/EWIS SPEAKER 4 DUAL CONE DRIVER of brand Australian Monitor.

SALIN is a leading Australian appliance spare parts distributer . We take pride in our ability to bring hard to find appliance spare parts into the Australian market. We are proudly Australian owned and operated. Our warehouse and sales office is conveniently located in Auburn, NSW. Our range of spare parts are manufactured with premium components and quality material. Most of our range is directly sourced from manufacturers and geniune.

TECHNICAL SHEET
Title EVAC/EWIS SPEAKER 4 DUAL CONE DRIVER
Notes The ATC5101-6 is high quality 4 inch surface mount ceiling speaker.Designed for the Evacuation and general PA market, the ATC5101-6 offers a 5 position terminal block, line supervisory capacitor and transformer cover as standard. It has a wide frequency response and extremely high sensitivity critical to these markets.4 inch dual cone driver100v tappings 5,2.5,1,0.5,0.33 watts92 dB 1 watt @ 1 meterEVAC cap installedCutout diameter 115mmDepth 110mm
DescriptionSpeaker. 5W, 4', 8 ohm, with 100V Taps at 5, 2.5, 1, .5 and .33W. Fitted with supervisory capacitor and transformer cover
ManufacturerAustralian Monitor
SKU NoWES_ATC5101-6_3



SALIN is not responsible for any possible damage caused by misselection and incorrect installation of the spare parts.

All electrical items must be fitted by a qualified electrician.

Errors and Omissions Excepted:

All information contained herein this website is assumed to be accurate, however, no responsibility is assumed by SALIN  for its use, nor for any infringements of patents or other rights of third parties which may result from its use.

Legal Disclaimer:

All trademarks, logos and principal representations remain the property of their respective owners. The use of brands, brand names and trademarks doesn't imply SALIN is representing those brands, companies, trademarks or names. SALIN holds no rights to products and/or services available or provided by the said companies, brands, brand names and trademarks.

MPN
SKU WES_ATC5101-6_3
Brand Australian Monitor
