Daikin 4 Way Reversing Valve Body

Genuine Daikin four way reversing valve body. This is the valve in the outdoor unit that switches the direction of refrigerant flow to change the system between cooling and heating, and to run a defrost cycle. Supplied as the valve body.

Part Numbers

Primary part number: 2343727

Cross-references and supersessions: 300822P, 1924767, 2320678.

Valve manufacturer code: STF-0731G. If you are matching the valve itself rather than the Daikin number, that is the code stamped on the body.

Search terms: 2343727, 300822P, 1924767, 2320678, STF-0731G, STF0731G, Daikin reversing valve, Daikin 4 way valve, Daikin four way valve body.

Brands Covered

Daikin.

Suitable Models

RZQ180MY1, RZQ180M2Y1, RZQ200MY1, RXYMQ8ATL, RXYMQ9ATL, RBCZQ7AAY, RBCZQ8AAY, RBCZQ9AAY, RTCZQ8AAY.

These are commercial Sky Air and VRV outdoor units. Quote your full outdoor unit model and serial from the nameplate when you order and we will confirm the valve before dispatch - reversing valves are sized to the system and are not interchangeable across capacities.

Symptoms Of A Failed Reversing Valve

• System will only cool, or will only heat - will not change over
• Unit runs but blows cool air on heating and warm air on cooling
• Valve does not shift when the solenoid is energised
• Continuous hissing or gurgling from the outdoor unit as refrigerant bleeds internally
• Poor capacity in both modes - internal leak across the valve slide
• Unit will not complete a defrost cycle in heating

Check First

Before condemning the valve body, check the solenoid coil and its supply. A failed coil, an open circuit winding or a control fault gives the same no-changeover symptom and is far cheaper to replace than the valve.

OEM Genuine

This is an OEM genuine part. It is made by the original equipment manufacturer, the same company in the same factory that made the part fitted to your appliance when it was built, and it carries their part number. It is supplied to us without the appliance brand retail packaging, and that is the only reason it costs less than a boxed part bought from the brand. The part itself is the same part.

Safety - Licensed Trades Only

This part is fitted into a sealed refrigerant circuit. In Australia the work must be carried out by a technician holding a current ARC refrigerant handling licence. The system must be recovered, the valve brazed in under nitrogen purge to avoid internal oxidisation, then evacuated and recharged to the nameplate. It is illegal to vent refrigerant to atmosphere.
