Fujitsu Lifestyle Indoor Unit Louvre Gear Case Assembly H431
Brand: FUJITSU | Part No: 9387714012
SKU: FUJ_9387714012_3
Most of our items are in stock and will be dispatched within 3 working days.
In rare cases where an item needs to be sourced from our supplier, dispatch may take up to 7 working days.
Fujitsu Lifestyle Split System Indoor Unit Gear Case Assembly (H431)
Genuine Fujitsu gear case assembly, part reference H431, for the indoor unit of Fujitsu Lifestyle range wall-mounted inverter split system air conditioners. This is the gearbox that drives the horizontal air-direction louvre – replace it when the flap will not open or close, jams part-way, rattles, or the motor turns but the louvre does not move.
Part Numbers & Details
| Part number | 9387714012 |
| Fujitsu reference | Gear Case Assy H431 |
| Supplier code | 9387714012FU |
| Brand | Fujitsu (Fujitsu General) |
| Part type | Louvre Gear Case / Gearbox Assembly, indoor unit |
| Range | Fujitsu Lifestyle, wall-mounted inverter split system |
Fits These Indoor Units
| Indoor unit | Capacity | Matching outdoor unit |
|---|---|---|
| ASTG18KMTC | 5.0 kW | AOTG18KMTC |
| ASTG22KMTC | 6.0 kW | AOTG22KMTC |
| ASTG24KMTC | 7.1 kW | AOTG24KMTC |
Fujitsu systems are often quoted by the outdoor unit number. This gear case is an indoor unit part – if your system is an AOTG18/22/24KMTC outdoor paired with an ASTG18/22/24KMTC indoor head, this is the right part.
Symptoms of a Failed Gear Case
- Horizontal louvre will not open or close, or opens only part way.
- Flap sits crooked, or one end lags behind the other.
- Clicking, grinding or rattling from the front of the indoor unit when the louvre moves.
- Swing motor runs but the louvre does not follow – stripped gear teeth.
Before You Order
- Check the model number on the label inside the indoor unit, behind the front cover.
- If your model is not one of the three above, send us your model and serial number and we will confirm fitment.
- Fitting requires removing the indoor unit front panel. Isolate the power at the wall before starting, and use a licensed air conditioning technician if you are unsure.
| AIRLINK | |
| SKU | FUJ_9387714012_3 |
| Model # | 9387714012 |
| Brand | Fujitsu |
| Shipping Weight | 1.0000kg |
