Hisense Indoor Cross Flow Fan Blade

Genuine Hisense cross flow fan blade, also called the barrel blower or tangential fan. This is the long horizontal rotor that runs the width of the indoor head - it draws air across the coil and pushes it out through the louvres. It is the part that moves all the air in a wall-mounted split system.

Part Numbers

Primary part number: K1466014

Also written as K146-6014 and K 1466014.

Search terms: K1466014, Hisense fan blade, Hisense cross flow fan, Hisense barrel blower, tangential fan Hisense, HSA25R-i fan blade, Hisense indoor fan.

Brands Covered

Hisense.

Suitable Models

Hisense HSA25R-i. Also searched as HSA25R, HSA25R-I and HSA25.

Before you order: cross flow fans are matched by length, diameter and end-fitting, and they differ between indoor head sizes even within one brand. Measure the barrel end to end and check the shaft and bearing ends. If your model is not listed, send us those measurements and a photo of both ends and we will confirm before we dispatch.

Symptoms Of A Failed Fan Blade

• Loud rattle, buzz or vibration from the indoor head that rises with fan speed
• Airflow dropped off noticeably with the fan still running
• Blades cracked, snapped, or clogged solid with dust and mould
• Barrel out of balance so the whole head shakes
• Rubbing or scraping noise as the fan touches the housing
• Fan seized, or turning but slipping on the motor shaft

OEM Genuine

This is an OEM genuine part. It is made by the original equipment manufacturer, the same company in the same factory that made the part fitted to your appliance when it was built, and it carries their part number. It is supplied to us without the appliance brand retail packaging, and that is the only reason it costs less than a boxed part bought from the brand. The part itself is the same part.

Fitting Notes

Isolate the unit at the isolator before starting. The head has to come off the wall bracket and the drain tray and coil have to be moved aside to release the barrel - it is not a front-panel job. Note which end carries the bearing and which takes the motor shaft before removing it. Clean the drain tray and the coil while the unit is open, since that is what the dust came off in the first place.

SALIN is not responsible for any possible damage caused by misselection and incorrect installation of the spare parts.

All electrical items must be fitted by a qualified electrician.
