This is a replacement rego 250mj/h mco twin stage regulator with pigtails.

SALIN is a leading Australian appliance spare parts distributor specializing in REGO PRODUCTS appliances. We take pride in our ability to bring hard-to-find REGO PRODUCTS spare parts into the Australian market. We are proudly Australian-owned and operated. Our sales office is conveniently located in Sydney, NSW. Most of our REGO PRODUCTS range is genuine.

TECHNICAL SHEET
TitleREGO 250MJ/h MCO Twin Stage Regulator with Pigtails for LPG CARAVAN SHOP RESTUARANT
BrandRegO Products
Notes

REGO™ twin stage regulator kit 250MJ/h 1/2″ outlet, c/w Manual changeover valve and 2x 20″ copper pigtails.

Description:

Kit comes with:

  • REGO™ twin stage regulator, guaranteed 250MJ/h @ 2.75kPa
  • Manual changeover (MCO) 2 bottle adapter
  • 20″ (500mm) long copper pigtails x2
  • Mounting bracket
  • Regulator to bracket bolts x2
  • Bracket mounting screws x2
  • Spanner
Application:

This regulator is ideal for caravan & house LPG installations, (<250MJ/h) it comes with all the bits to mount the regulator and connect to two gas cylinders, with manual change over between cylinders. It includes two copper pigtails (20″) for permanent cylinder installation (usually 45kg) and comes with a 1/2″ NPT female outlet, adapters to pipework sold separately.

Features:

This regulator has been tested for Australian conditions and has been rated to deliver a guaranteed 250MJ/h at 2.75kpa (11″ WC).

  • Includes a manual changeover valve for operating two cylinders or banks, one at a time.
  • Large vent helps prevent blockage.
  • 1st stage vent outlet is tapped ⅛” female NPT for vent piping.
  • Second stage vent outlet is tapped to ⅜”female NPT for vent piping.
  • With 15 PSIG inlet pressure, the regulator is designed to not pass more than 2 PSIG downstream with the seat disc removed (complies with over pressure protection requirements).
  • Incorporates an integral relief valve on second stage.
  • Unique bonnet vent profile minimises freezing over of vents when properly installed.
  • Compact design saves space allowing for easy installation – especially under container hoods with collars.
  • Pre-tapped & plugged test point outlets 1/8” female NPT on both 1st stage and second stage outlet.
  • Plugs can be removed with a 3/16” hex (Allen) wrench.
  • Select brown finish.
Notes:

Images are representative of the type of regulator and are not necessarily the actual kit described.

SKU NumberGMC_000948



SALIN is not responsible for any possible damage caused by misselection and incorrect installation of the spare parts.

All electrical items must be fitted by a qualified electrician.

Errors and Omissions Excepted:

All information contained herein this website is assumed to be accurate, however, no responsibility is assumed by SALIN  for its use, nor for any infringements of patents or other rights of third parties which may result from its use.

Legal Disclaimer:

All trademarks, logos and principal representations remain the property of their respective owners. The use of brands, brand names and trademarks doesn't imply SALIN is representing those brands, companies, trademarks or names. SALIN holds no rights to products and/or services available or provided by the said companies, brands, brand names and trademarks.

MPN
SKU GMC_000948
Brand Universal
Shipping Weight 1.0000kg
