This is a replacement rego 450mj/h twin stage mco regulator with long pigtails.

SALIN is a leading Australian appliance spare parts distributor specializing in REGO PRODUCTS appliances. We take pride in our ability to bring hard-to-find REGO PRODUCTS spare parts into the Australian market. We are proudly Australian-owned and operated. Our sales office is conveniently located in Sydney, NSW. Most of our REGO PRODUCTS range is genuine.

TECHNICAL SHEET
TitleREGO 450MJ/h Twin Stage MCO Regulator with Long Pigtails for LPG CARAVAN SHOP RESTUARANT
BrandRegO Products
Notes

REGO™ Twin Stage Regulator kit 450MJ/h 3/4″ outlet, c/w Manual changeover valve and 2x 36″ copper pigtails

Description:

Kit comes with:

  • REGO™ twin stage regulator, guaranteed 450MJ/h @ 2.75kPa
  • Manual changeover (MCO) 2 bottle adapter
  • 36″ (915mm) annealed copper pigtails x2
  • Mounting bracket
  • Regulator to bracket bolts x2
Application:

This regulator is great for medium sized house installations, (<450MJ/h) it comes with all the bits to mount the regulator and connect to the cylinder (bracket mounting screws 3403SCW sold separately). Comes with longer pigtails for connections to manifold or 190/210kg cylinders. It has a 3/4″ NPT female outlet, adapters to pipework sold separately.

Special Features:

This regulator has been tested for Australian conditions and has been rated to deliver a guaranteed 450MJ/h at 2.75kpa (11″ WC).

  • Includes a manual changeover valve for operating two cylinders or banks, one at a time.
  • Large vent helps prevent blockage.
  • 1st stage vent outlet is tapped ⅛” female NPT for vent piping.
  • Second stage vent outlet is tapped to ⅜”female NPT for vent piping.
  • With 15 PSIG inlet pressure, the regulator is designed to not pass more than 2 PSIG downstream with the seat disc removed (complies with over pressure protection requirements).
  • Incorporates an integral relief valve on second stage.
  • Unique bonnet vent profile minimises freezing over of vents when properly installed.
  • Compact design saves space allowing for easy installation – especially under container hoods with collars.
  • Pre-tapped & plugged test point outlets 1/8” female NPT on both 1st stage and second stage outlet.
  • Plugs can be removed with a 3/16” hex (Allen) wrench.
  • Select brown finish.
Notes:

Images are representative of the type of regulator and are not necessarily the actual kit described.

The main picture shows a single bottle kit whilst the second photo shows a representation of the type of pigtail included.

SKU NumberGMC_000899
