Samsung Washer Dryer Combo Door Boot Seal Gasket

Replacement door boot seal (door gasket, door bellows) for Samsung front loading washer dryer combos. This is the flexible rubber sleeve between the outer door frame and the drum. It is what fails when the machine starts leaking onto the floor mid-cycle, or when the rubber tears and begins catching and marking clothes.

Part Numbers

• DC64-03235B – Samsung part number

Our SKU for this item is EBY2_275311286212.

OEM Genuine

This is an OEM genuine part. It is made by the original equipment manufacturer, the same company in the same factory that made the part fitted to your appliance when it was built, and it carries their part number. It is supplied to us without the appliance brand retail packaging, and that is the only reason it costs less than a boxed part bought from the brand. The part itself is the same part.

Suitable Brand

• Samsung

The WD75 and WD85 series are Samsung washer dryer combos sold in Australia and New Zealand. Note that the suffix after the slash is the market code – /SA for Australia, /NZ for New Zealand – and does not change the seal.

Suitable Models

• Samsung WD75J5410AW, WD75J5410AW/SA
• Samsung WD75K54100W, WD75K54100W/NZ
• Samsung WD75K5410OW, WD75K5410OW/NZ
• Samsung WD75M4453JW, WD75M4453JW/SA
• Samsung WD85T554DBW, WD85T554DBW/SA

If your model is not on this list, send us the full model number and serial number from the sticker inside the door and we will check it before you buy.

When to Replace the Door Seal

• Water running out of the door onto the floor during the wash or spin
• A split, tear or hole in the rubber, most often along the bottom where water and grit collect
• Black mould in the folds that will not clean off and keeps returning
• Clothes snagging, tearing or coming out marked
• The rubber has gone hard or lost its shape and no longer seals against the door glass
• A smell from the machine that comes straight back after cleaning

Fitting

Turn the machine off at the wall and turn off the water. The seal is held by two clamps: an outer spring band around the door frame and an inner clamp on the drum lip. Release the outer band first, fold the seal back into the drum, then release the inner clamp and lift the old seal out. Fit the new seal onto the drum lip first, making sure any drain hole or moulded mark sits at the bottom, then seat the outer lip and refit both clamps. Run a short rinse and check for leaks before putting a full load in.

SAMSUNG WASHING MACHINE DOOR GASKET
