SB ACOUSTICS SPEAKER KITS - MICRO
PARTS SOLD SEPARATE
SKU code: WES_MICRO-ORHGL_1
This is a SB ACOUSTICS SPEAKER KITS - MICRO of brand SB Acoustics.
SALIN is a leading Australian appliance spare parts distributer . We take pride in our ability to bring hard to find appliance spare parts into the Australian market. We are proudly Australian owned and operated. Our warehouse and sales office is conveniently located in Auburn, NSW. Our range of spare parts are manufactured with premium components and quality material. Most of our range is directly sourced from manufacturers and geniune.
| TECHNICAL SHEET | |
|---|---|
| Title | SB ACOUSTICS SPEAKER KITS - MICRO |
| Notes | PARTS SOLD SEPARATE The Micro is a compact 2-way ideal for bookshelf, desktop, and smaller system use. Treat yourself to far better sound quality than comparable pre-assembled consumer speakers can offer. This little speaker kit packs a punch and sounds great doing it! The parts listed is everything required to make a stereo pair of speakers. The cabinets are completely assembled and have a stylish matte satin or high-gloss finish. The driver holes are precision cut for flush mounting of the tweeters and woofers. A slotted port is built into the front baffle for bass extension below 70Hz. The rear of the cabinet is pre-drilled for the included binding posts. Internal damping material and driver mounting hardware is included. The crossovers (sold separate) are pre-wired and terminated with slide on quick connects for the drivers. No soldering is required, and kit assembly can be completed with a screwdriver. Cabinets are sold in pairs (order one to receive a pair). Drivers and crossover are sold separate.Compact design 260x130x170mm 4.2Kg (ea.) no grillesOptimized for SBA Aluminium midwoofers and ¾ soft dome tweeterHigh quality component 2 way crossover 4KHzFront firing integrated slot port tuned to 49HzCabinets are 15mm assembled, painted, single-wiring binding postsRecommended amplifier 25-100W. Sensitivity is ~85dB(1W/1m) Cabinets and crossovers are each sold in pairs (order one to receive a pair). Drivers are sold as single units. |
| Description | Micro Cabinet Pair - Orange High Gloss |
| Colour | Orange High Gloss |
| Crossover | 4000Hz (18dB) |
| Freq. | 70Hz - 28000Hz |
| Impedance (Ohm) | 4 Ohm |
| Material | 18mm MDF |
| Ohm | 4 |
| Power | 25-100W |
| QTY | 2 |
| Sold As | Pairs |
| Size | 260x130x170mm |
| SPL | 100dB |
| Tweeter | SB19ST-C000-4 |
| Weight | 4.2Kg pair |
| Woofer | SB12PAC25-4 |
| Price Type | Pair |
| Series | Speaker Kit |
| Type | Cabinet |
| Manufacturer | SB Acoustics |
| eBook | Link to eBook |
| Page | 4 |
| SKU No | WES_MICRO-ORHGL_1 |
