SB AUDIENCE 1.4 COMPRESSION DRIVER 70W
65MM VC WITH FERRITE MAGNET
SKU code: WES_ROSSO-65CD-T_1
This is a SB AUDIENCE 1.4 COMPRESSION DRIVER 70W of brand SB Audience.
SALIN is a leading Australian appliance spare parts distributer . We take pride in our ability to bring hard to find appliance spare parts into the Australian market. We are proudly Australian owned and operated. Our warehouse and sales office is conveniently located in Auburn, NSW. Our range of spare parts are manufactured with premium components and quality material. Most of our range is directly sourced from manufacturers and geniune.
| TECHNICAL SHEET | |
|---|---|
| Title | SB AUDIENCE 1.4 COMPRESSION DRIVER 70W |
| Notes | 65MM VC WITH FERRITE MAGNET Titanium diaphragm for Extended upper frequency responseCopper cap for reduced distortion and extended HF responseAdvanced ferrite motor assemblyHigh sensitivity and linear frequency responseAdvanced voice coil with flat copper clad aluminium wire 2 hour AES test made with continuous pink noise signal within the range from the recommended crossover frequency to 20kHz. Maximum power is defined as 3dB greater than nominal power. Test is carried out with driver mounted on HORN-H250. |
| Description | 1.4' - Compression Driver 70W - 110dB - 8Ohm |
| Coil | 65mm |
| Depth | 65.94mm |
| Freq. | 500-20000Hz |
| Impedance | 8Ω |
| Impedance (Ohm) | 8 ohm |
| Inch | 1.4' |
| Manufacturer | SB Audience |
| Materials | Kapton |
| Pmax | 140W |
| Power | 70W AES |
| Power (RMS) | 51-100 Watt |
| Price Type | each |
| Prms | 70W |
| QTY | 1 |
| Sens. | 110dB |
| Series | SB Pro-compression drivers |
| Size | 1.4' |
| Type | Compression driver |
| Width | 156mmØ |
| Zn | 8Ω |
| Page | 46 |
| eBook | Link to eBook |
| Brand. | SB Accoustics |
| SKU No | WES_ROSSO-65CD-T_1 |
